Clamp weld ferrule Clamp × weld end

Clamp (tri-clamp) couplings are hygienic couplings for food lines: two ferrules are clamped together over a seal. Smooth bore without gaps, quick to dismantle for cleaning. DN 25–104.

Inner diameter: 25–104 mm
System: Clamp (tri-clamp)
Material: Stainless steel
Connection: Weld end

Request a quote

Seals for this coupling are in Seals and gaskets.

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 25, 38, 51, 63, 76, 104
Coupling system: Clamp (tri-clamp)
Body material: Stainless steel
Connection: Weld end

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Article
25	304025
38	304038
51	304051
63	304063
76	304076
104	304104

Application and limits

Application: Clamp (tri-clamp) couplings are hygienic couplings for food lines: two ferrules are clamped together over a seal. Smooth bore without gaps, quick to dismantle for cleaning.
Features: Quick assembly and dismantling with a clamp, smooth bore without gaps — easy to clean, for food and pharmaceutical lines
Limits: Working pressure and temperature depend on the size, body material and seal — please check when ordering.
