DIN 11851 gasket for blank caps, NBR Gasket for DIN 11851 blank caps
NBR gasket for DIN 11851 blank caps with female thread. Size by the nominal size of the cap. DN 25–100.
- Inner diameter
- 25–100 mm
- System
- DIN 11851
- Connection
- Seal
Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.
We can assemble the hose with couplings and pressure test it — service.
Specifications
- Inner diameter, mm
- 25, 32, 38, 50, 63, 75, 100
- Coupling system
- DIN 11851
- Connection
- Seal
Sizes and article numbers
Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.
| DN, mm | Size | Article | Weight, kg |
|---|---|---|---|
| 25 | 52 × 3 mm | 217025 | 0.009 |
| 32 | 58 × 3 mm | 217032 | 0.012 |
| 38 | 65 × 3 mm | 217038 | 0.015 |
| 50 | 78 × 3 mm | 217050 | 0.022 |
| 63 | 95 × 3 mm | 217063 | 0.031 |
| 75 | 110 × 3 mm | 217075 | 0.041 |
| 100 | 130 × 3 mm | 217100 | 0.079 |
Application and limits
- Application
- NBR gasket for DIN 11851 blank caps with female thread. Size by the nominal size of the cap.
- Features
- Sized to the coupling
- Limits
- Working pressure and temperature depend on the size, body material and seal — please check when ordering.
