Macon nut Nut for Macon couplings
Macon is a threaded food coupling widely used in the wine and food industry. Parts are made of 316L stainless steel. DN 38–103.
- Inner diameter
- 38–103 mm
- System
- Macon
- Material
- Stainless steel 316L
- Connection
- Coupling part
Seals for this coupling are in Seals and gaskets.
Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.
We can assemble the hose with couplings and pressure test it — service.
Specifications
- Inner diameter, mm
- 38, 53, 63, 73, 83, 103
- Coupling system
- Macon
- Body material
- Stainless steel 316L
- Connection
- Coupling part
Sizes and article numbers
Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.
| DN, mm | Article |
|---|---|
| 38 | 342043038 |
| 53 | 342053051 |
| 63 | 342063063 |
| 73 | 342073070 |
| 83 | 342083076 |
| 103 | 343103101 |
Application and limits
- Application
- Macon is a threaded food coupling widely used in the wine and food industry. Parts are made of 316L stainless steel.
- Features
- 316L stainless steel, for the wine and food industry
- Limits
- Working pressure and temperature depend on the size, body material and seal — please check when ordering.
