Perrot end cap Perrot-type ball joint coupling
Perrot-type ball joint couplings for pipes and hoses: the ball joint allows the line to deflect at an angle. Sizes by pipe outer diameter. Galvanized steel; OPTIMA — stainless steel; SUPRA — stainless and galvanized steel. Pipe 50–159 mm.
- System
- Perrot
- Material
- Galvanized steel, Stainless and galvanized steel (SUPRA), Stainless steel (OPTIMA)
- Connection
- Cap
Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.
We can assemble the hose with couplings and pressure test it — service.
Specifications
- Coupling system
- Perrot
- Body material
- Galvanized steel, stainless and galvanized steel (SUPRA), stainless steel (OPTIMA)
- Connection
- Cap
Sizes and article numbers
Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.
| Article | Pipe OD, mm | Part | Material |
|---|---|---|---|
| KVX 50 | 50 | male | Galvanized steel |
| KVX 70 | 70 | male | Galvanized steel |
| KVX 89 | 89 | male | Galvanized steel |
| KVX 108 | 108 | male | Galvanized steel |
| KVX 133 | 133 | male | Galvanized steel |
| KVX 159 | 159 | male | Galvanized steel |
| KMX 50 | 50 | female | Galvanized steel |
| KMX 70 | 70 | female | Galvanized steel |
| KMX 89 | 89 | female | Galvanized steel |
| KMX 108 | 108 | female | Galvanized steel |
| KMX 133 | 133 | female | Galvanized steel |
| KMX 159 | 159 | female | Galvanized steel |
| KVX 50/OPTIMA | 50 | male | Stainless steel (OPTIMA) |
| KVX 70/OPTIMA | 70 | male | Stainless steel (OPTIMA) |
| KVX 89/OPTIMA | 89 | male | Stainless steel (OPTIMA) |
| KVX 108/OPTIMA | 108 | male | Stainless steel (OPTIMA) |
| KVX 133/OPTIMA | 133 | male | Stainless steel (OPTIMA) |
| KVX 159/OPTIMA | 159 | male | Stainless steel (OPTIMA) |
| KMX 50/SUPRA | 50 | female | Stainless and galvanized steel (SUPRA) |
| KMX 70/SUPRA | 70 | female | Stainless and galvanized steel (SUPRA) |
| KMX 89/SUPRA | 89 | female | Stainless and galvanized steel (SUPRA) |
| KMX 108/SUPRA | 108 | female | Stainless and galvanized steel (SUPRA) |
| KMX 133/SUPRA | 133 | female | Stainless and galvanized steel (SUPRA) |
| KMX 159/SUPRA | 159 | female | Stainless and galvanized steel (SUPRA) |
| KMX 50/OPTIMA | 50 | female | Stainless steel (OPTIMA) |
| KMX 70/ OPTIMA | 70 | female | Stainless steel (OPTIMA) |
| KMX 89/ OPTIMA | 89 | female | Stainless steel (OPTIMA) |
| KMX 108/ OPTIMA | 108 | female | Stainless steel (OPTIMA) |
| KMX 133/ OPTIMA | 133 | female | Stainless steel (OPTIMA) |
| KMX 159/ OPTIMA | 159 | female | Stainless steel (OPTIMA) |
Application and limits
- Application
- Perrot-type ball joint couplings for pipes and hoses: the ball joint allows the line to deflect at an angle. Sizes by pipe outer diameter. Galvanized steel; OPTIMA — stainless steel; SUPRA — stainless and galvanized steel.
- Features
- Ball joint allows angular deflection
- Limits
- Working pressure and temperature depend on the size, material and seal — please check when ordering.
