Perrot reducer Perrot-type ball joint coupling

Perrot-type ball joint couplings for pipes and hoses: the ball joint allows the line to deflect at an angle. Sizes by pipe outer diameter. Galvanized steel; OPTIMA — stainless steel; SUPRA — stainless and galvanized steel. Pipe 50–159 mm.

System: Perrot
Material: Galvanized steel
Connection: Coupling part

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Coupling system: Perrot
Body material: Galvanized steel
Connection: Coupling part

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

Article	Pipe OD, mm	Material
KKMGV 70 x 50	70	Galvanized steel
KKMGV 89 x 50	89	Galvanized steel
KKMGV 89 x 70	89	Galvanized steel
KKMGV 108 x 70	108	Galvanized steel
KKMGV 108 x 89	108	Galvanized steel
KKMGV 133 x 89	133	Galvanized steel
KKMGV 133 x 108	133	Galvanized steel
KKMGV 159 x 108	159	Galvanized steel
KKMGV 159 x 133	159	Galvanized steel
KGMKV 50 x 70	50	Galvanized steel
KGMKV 50 x 89	50	Galvanized steel
KGMKV 70 x 89	70	Galvanized steel
KGMKV 70 x 108	70	Galvanized steel
KGMKV 89 x 108	89	Galvanized steel
KGMKV 89 x 133	89	Galvanized steel
KGMKV 89 x 159	89	Galvanized steel
KGMKV 108 x 133	108	Galvanized steel
KGMKV 108 x 159	108	Galvanized steel
KGMKV 133 x 159	133	Galvanized steel

Application and limits

Application: Perrot-type ball joint couplings for pipes and hoses: the ball joint allows the line to deflect at an angle. Sizes by pipe outer diameter. Galvanized steel; OPTIMA — stainless steel; SUPRA — stainless and galvanized steel.
Features: Ball joint allows angular deflection
Limits: Working pressure and temperature depend on the size, material and seal — please check when ordering.
