Drawing: Storz coupling with barbed hose tail

Storz coupling with barbed hose tail Storz head × barbed hose tail, for suction and delivery hoses

Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs. DN 52–150.

Inner diameter: 52–150 mm
System: Storz
Connection: Hose tail

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 52, 75, 100, 150
Coupling system: Storz
Connection: Hose tail

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Lug distance, mm	Article	Weight, kg
52	66	242052066	0.37
75	89	242075089	0.795
100	133	242100133	1.738
150	160	242150160	2.8

Application and limits

Application: Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.
Features: Symmetrical coupling — no male and female parts, connects with a quarter turn
Limits: Working pressure and temperature depend on the size, material and seal — please check when ordering.
