Drawing: KS safety clamp DIN 2817, aluminium

KS safety clamp DIN 2817, aluminium Two-piece safety clamp with four bolts

Two-piece KS safety clamp to DIN 2817 with four bolts — holds the hose securely on the hose tail in fuel and industrial hose assemblies. DN 13–200.

Inner diameter: 13–200 mm
System: DIN 2817
Material: Aluminium
Connection: Coupling part

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 13, 19, 25, 32, 38, 40, 50, 63, 65, 75, 80, 100, 125, 150, 200
Coupling system: DIN 2817
Body material: Aluminium
Connection: Coupling part

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

Hose ID, mm	Article	Hose wall, mm	Hose OD, mm	Weight, kg
13	KS.013 5 AL	5	22–24	0.108
19	KS.019 6 AL	6	30–33	0.138
25	KS.025 6 AL	6	36–39	0.138
25	KS.025 8 AL	8	40–43	—
32	KS.032 6 AL	6	43–46	0.154
32	KS.032 8 AL	8	47–50	0.163
38	KS.038 10 AL	10	57–60	0.187
38	KS.038 5 AL	5	47–49	—
38	KS.038 6,5 AL	6.5	50–52	0.17
38	KS.038 8 AL	8	53–56	0.17
40	KS.040 10 AL	10	58–61	0.19
40	KS.040 7 AL	7	53–56	0.174
50	KS.050 10 AL	10	69–71	0.31
50	KS.050 6 AL	6	61–63	—
50	KS.050 8 AL	8	63–67	0.286
63	KS.063 6 AL	6	74–76	—
63	KS.063 8 AL	8	78–82	0.412
65	KS.065 10 AL	10	84–87	0.45
75	KS.075 10 AL	10	94–97	0.51
75	KS.075 12 AL	12	98–101	—
75	KS.075 8 AL	8	88–93	0.47
80	KS.080 10 AL	10	99–102	—
80	KS.080 8 AL	8	94–97	0.456
100	KS.100 10 AL	10	118–122	1.2
100	KS.100 12 AL	12	122–126	1.384
100	KS.100 14 AL	14	126–130	—
100	KS.100 16 AL	16	130–134	—
100	KS.100 8 AL	8	114–119	1.176
125	KS.125 10 AL	10	143–148	2.092
125	KS.125 15 AL	15	153–158	—
150	KS.150 10 AL	10	168–174	3.405
150	KS.150 13 AL	13	174–180	3.455
150	KS.150 15 AL	15	178–184	—
200	KS.200 12 AL	12	222–229	5.74

Application and limits

Application: Two-piece KS safety clamp to DIN 2817 with four bolts — holds the hose securely on the hose tail in fuel and industrial hose assemblies.
Features: Four bolts — even clamping, for hose assemblies to DIN 2817
Limits: Working pressure and temperature depend on the size, body material and seal — please check when ordering.
