MEKA hose coupling, brass MEKA hose coupling: thread × smooth tail with safety sleeve

MK/VK couplings are used for loading and unloading oil products from rail and road tank cars. The MK coupling with handle connects to the VK adapter; MB and VB caps close them in transit. MEKA hose couplings attach the hose to the fittings. DN 13–100.

Inner diameter: 13–100 mm
System: MEKA
Material: Brass
Connection: Hose tail

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 13, 19, 25, 32, 38, 50, 63, 75, 80, 100
Coupling system: MEKA
Body material: Brass
Connection: Hose tail

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Article	Pack, pcs	Weight, kg
13	MEKA.013	13	0.069
19	MEKA.019	19	0.1
25	MEKA.025	25	0.14
32	MEKA.032	32	0.216
38	MEKA.038	38	0.297
38	MEKA.038 G2	38	0.431
50	MEKA.050	50	0.343
63	MEKA.063	63	0.613
75	MEKA.075	75	0.832
80	MEKA.080	—	—
100	MEKA.100	100	1.68

Application and limits

Application: MK/VK couplings are used for loading and unloading oil products from rail and road tank cars. The MK coupling with handle connects to the VK adapter; MB and VB caps close them in transit. MEKA hose couplings attach the hose to the fittings.
Features: For fuels, oils and oil products, quick connection with a handle coupling
Limits: Working pressure and temperature depend on the size, body material and seal — please check when ordering.
