Drawing: MEKA GU hose coupling, stainless steel

MEKA GU hose coupling, stainless steel MEKA GU hose coupling: union nut × smooth tail with safety sleeve

MK/VK couplings are used for loading and unloading oil products from rail and road tank cars. The MK coupling with handle connects to the VK adapter; MB and VB caps close them in transit. MEKA hose couplings attach the hose to the fittings. DN 13–100.

Inner diameter: 13–100 mm
System: MEKA
Material: Stainless steel
Connection: Hose tail

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 13, 19, 25, 32, 38, 50, 63, 76, 100
Coupling system: MEKA
Body material: Stainless steel
Connection: Hose tail

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Article	Pack, pcs	Weight, kg
13	SSMEKA GU.013	25	0.105
19	SSMEKA GU.019	20	0.085
25	SSMEKA GU.025	16	0.117
32	SSMEKA GU.032	14	0.179
38	SSMEKA GU.038	15	0.277
50	SSMEKA GU.050	12	0.372
63	SSMEKA GU.063	9	0.679
76	SSMEKA GU.076	6	0.966
100	SSMEKA GU.100	4	2.05

Application and limits

Application: MK/VK couplings are used for loading and unloading oil products from rail and road tank cars. The MK coupling with handle connects to the VK adapter; MB and VB caps close them in transit. MEKA hose couplings attach the hose to the fittings.
Features: For fuels, oils and oil products, quick connection with a handle coupling
Limits: Working pressure and temperature depend on the size, body material and seal — please check when ordering.
