Storz–Storz reducer Reducer between two Storz sizes

Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.

System: Storz
Connection: Coupling part

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Coupling system: Storz
Connection: Coupling part

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Lug distance, mm	Article	Weight, kg
—	31–66	247031066	0.319
—	52–66	247052066	0.594
—	66–81	247066081	0.788
—	66–89	247066089	0.591
—	81–89	247081089	0.987
—	89–133	247089133	1.52

Application and limits

Application: Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.
Features: Symmetrical coupling — no male and female parts, connects with a quarter turn
Limits: Working pressure and temperature depend on the size, material and seal — please check when ordering.
