Drawing: Storz spray branch with adapter

Storz spray branch with adapter Spray branch with Storz adapter, aluminium alloy

Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.

System: Storz
Material: Aluminium alloy
Connection: Coupling part

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Coupling system: Storz
Body material: Aluminium alloy
Connection: Coupling part

Sizes and article numbers

Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.

DN, mm	Lug distance, mm	Article	Material	Weight, kg
—	66	252066129	Aluminium alloy	1.544
—	81	252081129	Aluminium alloy	1.655

Application and limits

Application: Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.
Features: Symmetrical coupling — no male and female parts, connects with a quarter turn
Limits: Working pressure and temperature depend on the size, material and seal — please check when ordering.
