Storz swivel adapter with female thread Swivel Storz head × female thread
Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs. DN 52–110.
- Inner diameter
- 52–110 mm
- System
- Storz
- Connection
- Female thread
Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.
We can assemble the hose with couplings and pressure test it — service.
Specifications
- Inner diameter, mm
- 52, 75, 110
- Coupling system
- Storz
- Connection
- Female thread
Sizes and article numbers
Each size is a separate item with its own article number. Searching the site by article number takes you straight to the row.
| DN, mm | Lug distance, mm | Article |
|---|---|---|
| 52 | 66 | 246052066 |
| 75 | 89 | 246075089 |
| 110 | 133 | 246110133 |
Application and limits
- Application
- Storz couplings are symmetrical: two identical heads with lugs connect with a quarter turn, without male and female parts. The size of a Storz head is set by the distance between the lugs.
- Features
- Symmetrical coupling — no male and female parts, connects with a quarter turn
- Limits
- Working pressure and temperature depend on the size, material and seal — please check when ordering.
