DELMARINE FUEL 10 D hose with layers partly removed: inner tube, reinforcement and cover

DELMARINE FUEL 10 D Marine fuel delivery hose for leisure boats

Fuel delivery hose for diesel, biodiesel and petrol to marine engines on leisure boats up to 24 m. Inner diameter 19–51 mm, working pressure up to 10 bar, temperature from −20 to +100 °C.

Inner diameter: 19–51 mm
Working pressure: up to 10 bar
Mode: pressure only
Temperature: −20…+100 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 19, 25, 30, 32, 38, 40, 45, 51
Working pressure, bar: 10
Medium: Biodiesel, fuel
Mode: Pressure
Reinforcement: Textile cord
Temperature, °C: −20…+100
Tube material: NBR
Coil length, m: 40, 61

Construction

Inner tube: NBR rubber, black, smooth
Reinforcement: High strength synthetic textile plies
Cover: Chloroprene rubber (CR), black, smooth, cloth impression, self-extinguishing, resistant to weathering, fuels and heat
Electrical properties: Copper wire for grounding

DELMARINE FUEL 10 D sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Coil length, m
19	681019032	32	10	30	0.75	40
25	681025039	39	10	30	0.95	40, 61
30	681030044	44	10	30	1.22	40, 61
32	681032046	46	10	30	1.29	40, 61
38	681038052	52	10	30	1.36	40, 61
40	681040054	54	10	30	1.51	40, 61
45	681045059	59	10	30	1.62	40, 61
51	681051065	65	10	30	1.75	40, 61

Application and limits

Application: Fuel delivery hose for diesel, biodiesel and petrol to marine engines on leisure boats up to 24 m.
Features: Self-extinguishing cover, copper wire for grounding
Limits: Operating temperature from −20 to +100 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
For leisure boats up to 24 m long.
