DELOIL 10 D LL BRAID hose with layers partly removed: inner tube, reinforcement and cover

DELOIL 10 D LL BRAID Small bore fuel and oil hose with textile braid

Delivery hose for engines: mineral oils, lubricants, diesel and petrol with up to 50 % aromatics. Inner diameter 3–25 mm, working pressure up to 10 bar, temperature from −40 to +90 °C.

Inner diameter: 3–25 mm
Working pressure: up to 10 bar
Mode: pressure only
Temperature: −40…+90 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 3, 4, 5, 6, 7, 8, 10, 13, 16, 19, 25
Working pressure, bar: 10
Medium: Fuel, lubricants, mineral oil products
Mode: Pressure
Reinforcement: Textile braid
Temperature, °C: −40…+90
Tube material: NBR
Coil length, m: 50, 100

Construction

Inner tube: NBR rubber, black, smooth
Reinforcement: Single rubberised textile braid
Cover: Single rubberised textile braid

DELOIL 10 D LL BRAID sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Bend radius, mm	Weight, kg/m	Coil length, m
3	787003007	7	10	30	25	0.04	100
4	787004008	8	10	30	35	0.05	100
5	787005010	10	10	30	40	0.08	100
6	787006011	11	10	30	50	0.1	50
7	787007013	13	10	30	55	0.13	50
8	787008013	13	10	30	65	0.11	50
8	787008015	15	10	30	65	0.16	50
10	787010017	17	10	30	80	0.19	50
13	787013020	20	10	30	130	0.24	50
16	787016023	23	10	30	160	0.28	50
19	787019027	27	10	30	190	0.38	50
25	787025033	33	10	30	250	0.5	50

Application and limits

Application: Delivery hose for engines: mineral oils, lubricants, diesel and petrol with up to 50 % aromatics.
Features: Supplied in long coils
Limits: Operating temperature from −40 to +90 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
