DELOIL 15 LF hose with layers partly removed: inner tube, reinforcement and cover

DELOIL 15 LF Layflat hose for fuels and oils

Layflat delivery hose for fuels and petroleum products with up to 50 % aromatics. Inner diameter 76–203 mm, working pressure up to 15 bar, temperature from −30 to +80 °C.

Inner diameter: 76–203 mm
Working pressure: up to 15 bar
Mode: pressure
Temperature: −30…+80 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 76, 102, 152, 203
Working pressure, bar: 15
Medium: Fuel, mineral oil products
Mode: Pressure, layflat
Reinforcement: Textile cord
Temperature, °C: −30…+80
Tube material: NBR
Coil length, m: 40, 60

Construction

Inner tube: NBR rubber, black, smooth
Reinforcement: High strength synthetic textile plies
Cover: SBR/NBR/PVC rubber, black, smooth, cloth impression, resistant to ozone, weathering, oils and fuels
Electrical properties: Copper wire for grounding

DELOIL 15 LF sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Coil length, m
76	790076087	87	15	45	1.7	40, 60
102	790102114	114	15	45	2.5	40, 60
152	790152164	164	15	45	3.8	40, 60
203	790203218	218	15	45	6.95	40

Application and limits

Application: Layflat delivery hose for fuels and petroleum products with up to 50 % aromatics.
Features: Lays flat when empty, copper wire for grounding
Limits: Operating temperature from −30 to +80 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
