Welding cable protection sleeve hose with layers partly removed: inner tube, reinforcement and cover

Welding cable protection sleeve Rubber sleeve for cables and welding torch packages

Textile reinforced rubber sleeve for protecting electrical cables and welding torch hose packages; electrical insulation above 5000 V. Inner diameter 19–51 mm, temperature from −30 to +80 °C.

Inner diameter: 19–51 mm
Mode: cable protection
Temperature: −30…+80 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 19, 22, 25, 28, 30, 32, 35, 38, 40, 42, 45, 51
Mode: Protective sleeve
Temperature, °C: −30…+80
Coil length, m: 40

Construction

Inner tube: Rubberised textile
Cover: SBR rubber, black, smooth, cloth impression, resistant to abrasion and weathering

Welding cable protection sleeve sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Weight, kg/m	Coil length, m
19	980019022	22	0.13	40
22	980022025	25	0.16	40
25	980025028	28	0.17	40
28	980028031	31	0.18	40
30	980030033	33	0.2	40
32	980032035	35	0.22	40
35	980035038	38	0.26	40
38	980038041	41	0.28	40
40	980040043	43	0.3	40
42	980042045	45	0.31	40
45	980045048	48	0.33	40
51	980051054	54	0.36	40

Application and limits

Application: Textile reinforced rubber sleeve for protecting electrical cables and welding torch hose packages; electrical insulation above 5000 V.
Features: Electrical insulation above 5000 V
Limits: Operating temperature from −30 to +80 °C.
