DELCHEM NH3 25 D hose with layers partly removed: inner tube, reinforcement and cover

DELCHEM NH3 25 D Anhydrous ammonia delivery hose, 25 bar

Delivery hose for anhydrous ammonia, mainly in fertiliser production. Inner diameter 19–76 mm, working pressure up to 25 bar, temperature from −40 to +120 °C.

Inner diameter: 19–76 mm
Working pressure: up to 25 bar
Mode: pressure only
Temperature: −40…+120 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 19, 25, 32, 38, 51, 76
Working pressure, bar: 25
Medium: Anhydrous ammonia
Mode: Pressure
Reinforcement: Textile cord
Temperature, °C: −40…+120
Tube material: EPDM
Coil length, m: 40

Construction

Inner tube: EPDM rubber, black, smooth, antistatic
Reinforcement: High strength synthetic textile plies
Cover: EPDM rubber, black, smooth, cloth impression, antistatic, resistant to ozone, weathering and chemicals
Electrical properties: Antistatic inner tube; antistatic cover

DELCHEM NH3 25 D sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Bend radius, mm	Weight, kg/m	Coil length, m
19	834019031	31	25	125	95	0.83	40
25	834025037	37	25	125	125	1.01	40
32	834032044	44	25	125	160	1.15	40
38	834038051	51	25	125	228	1.46	40
51	834051067	67	25	125	300	2.1	40
76	834076092	92	25	125	470	3.45	40

Application and limits

Application: Delivery hose for anhydrous ammonia, mainly in fertiliser production.
Features: Antistatic inner tube, up to +120 °C
Limits: Operating temperature from −40 to +120 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
