DELFLAT hose with layers partly removed: inner tube, reinforcement and cover

DELFLAT Rubber covered layflat hose

Multipurpose rubber covered layflat hose for construction sites, industry, agriculture and mining. Inner diameter 20–305 mm, working pressure up to 25 bar, temperature from −20 to +100 °C.

Inner diameter: 20–305 mm
Working pressure: up to 25 bar
Mode: pressure
Temperature: −20…+100 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 20, 26, 32, 35, 38, 45, 52, 55, 60, 65, 70, 76, 80, 90, 102, 110, 114, 120, 127, 152, 203, 254, 305
Working pressure, bar: 10, 14, 15, 16, 20, 25
Medium: Air, light slurry, water
Mode: Pressure, layflat
Reinforcement: Circular woven textile
Temperature, °C: −20…+100
Tube material: NBR/PVC
Coil length, m: 100

Construction

Inner tube: Special high grade formulated NBR / PVC compound extruded through the weave in a unique one step production process, special additives in the compound guarantee superior UV and ageing resistance, very smooth for minimum friction loss
Reinforcement: Textile. Warp: high tenacity polyester. Weft: polyamide, circular woven. The special weaving design offers a high tensile strength, superior adhesion level and flow performance compared to an all polyester weave. Totally embedded in the rubber compound, excellent protected against mechanical damage
Cover: Special high grade formulated NBR / PVC compound extruded through the weave in a unique one step production process

DELFLAT sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Wall thickness, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Tensile strength, kg	Coil length, m
20	646020024	2	25	75	0.16	1000	100
26	646026030	2	25	75	0.18	1200	100
32	646032036	2	20	60	0.23	1600	100
35	646035039	2	16	50	0.25	1600	100
38	646038042	2	16	50	0.28	1700	100
45	646045050	2.2	16	50	0.35	1700	100
52	646052057	2.2	16	50	0.4	3000	100
55	646055060	2.2	16	50	0.44	3800	100
60	646060065	2.2	16	50	0.47	4100	100
65	646065070	2.2	16	50	0.51	4300	100
70	646070075	2.3	16	50	0.6	6300	100
76	646076081	2.5	16	50	0.68	6500	100
80	646080085	2.5	16	50	0.75	7500	100
90	646090095	2.8	16	50	0.9	9500	100
102	646102108	2.8	16	50	1	9500	100
110	646110116	3	16	50	1.1	10500	100
114	646114120	3	15	45	1.15	10800	100
120	646120126	3	15	45	1.3	11000	100
127	646127133	3	15	45	1.4	12000	100
152	646152158	3	14	42	1.7	14000	100
203	646203209	3.3	10	30	2.4	18000	100
254	646254260	—	—	—	—	—	100
305	646305311	—	—	—	—	—	100

Application and limits

Application: Multipurpose rubber covered layflat hose for construction sites, industry, agriculture and mining.
Features: Hardwearing and very abrasion resistant, resistance to oil, fuel and a wide range of chemicals (see resistance table in technical appendix), resistance to heat, weathering and ozone, minimum pressure loss, very low elongation, very flexible and lightweight compared to mandril built hoses, no cleaning and drying required
Limits: Operating temperature from −20 to +100 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
Technical data based on water.
For air pressure the minimum safety ratio is 1:4.
Depending on the application our product can be operated with a maximum working pressure up to 50% of the bursting pressure.
Please consult us for approval. It is important to note, that the technical data for pressure are only valid for hose and not for hose assembly with couplings!
To obtain maximum lifetime the end pull under working conditions should not exceed 1/3 of the breaking strength.
Color according to customer specification.
Cold flexible version of hose (down to -30°C) on request.
Other lengths on request. Lengths up to 200 m.
