DELFLAT PU hose with layers partly removed: inner tube, reinforcement and cover

DELFLAT PU Polyurethane layflat hose

Multipurpose polyurethane layflat hose for construction sites, industry and agriculture. Inner diameter 25–356 mm, working pressure up to 20 bar, temperature from −50 to +75 °C.

Inner diameter: 25–356 mm
Working pressure: up to 20 bar
Mode: pressure
Temperature: −50…+75 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 25, 38, 52, 65, 76, 90, 102, 127, 152, 203, 254, 305, 356
Working pressure, bar: 4, 5, 7, 8, 10, 14, 16, 20
Medium: Abrasive media, slurry, waste water, water
Mode: Pressure, layflat
Reinforcement: Circular woven textile
Temperature, °C: −50…+75
Tube material: Polyurethane
Coil length, m: 100, 200

Construction

Inner tube: Thermoplastic polyether polyurethane extruded through the weave in a unique one step production process. Superior abrasion resistance 4-5 times better than NBR/PVC hoses. Very smooth for minimum friction loss
Reinforcement: Textile. High tenacity polyester yarn, circular woven. Special weaving design for continuous high pressure performance, high tensile strength and low elongation under pressure. Totally embedded in the PU compound, excellent protected against mechanical damage
Cover: Thermoplastic polyether polyurethane extruded through the weave in a unique one step production process. Superior abrasion resistance 4-5 times better than NBR/PVC hoses. Very smooth for good flexibility. Black color

DELFLAT PU sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Wall thickness, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Tensile strength, kg	Coil length, m
25	647025028	1.6	16	50	0.16	1200	100, 200
38	647038042	1.8	16	50	0.28	1700	100, 200
52	647052057	2.6	20	60	0.5	5000	100, 200
65	647065070	2.6	20	60	0.65	6500	100, 200
76	647076082	2.8	16	50	0.75	8000	100, 200
90	647090096	2.8	14	42	0.95	9000	100, 200
102	647102109	3.3	16	50	1.2	13200	100, 200
127	647127133	3	10	30	1.4	12000	100, 200
152	647152158	3	10	30	1.65	15000	100, 200
203	647203209	3	8	24	2.2	18500	100, 200
254	647254260	3.2	7	21	2.85	23500	100, 200
305	647305312	3.3	5	15	3.5	3800	100, 200
356	647356365	4.3	4	12	5.6	42000	100, 200

Application and limits

Application: Multipurpose polyurethane layflat hose for construction sites, industry and agriculture.
Features: Extremely hardwearing and durable for long service life, resistance to oil, fuel and a wide range of chemicals (see resistance table in technical appendix), resistance to weathering and ozone, flexible and lightweight compared to mandril built hoses, good handling, excellent cold flexibility, single lengths longer than 200 m (660 ft), 52 - 90 mm (2 - 3 1/2″) up to 500 m (1,650 ft), 102 - 127 mm (4 - 5″) up to 400 m (1,320 ft)
Limits: Operating temperature from −50 to +75 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
Technical data based on water.
For air pressure the minimum safety ratio is 1:4.
Depending on the application our product can be operated with a maximum working pressure up to 50 % of the bursting pressure. Please consult us for approval.
Other lengths on request.
