DELFLAT L hose with layers partly removed: inner tube, reinforcement and cover

DELFLAT L Lightweight PVC layflat hose

Lightweight PVC layflat hose for agriculture, industry and civil engineering. Inner diameter 38–407 mm, working pressure up to 5 bar, temperature from −10 to +60 °C.

Inner diameter: 38–407 mm
Working pressure: up to 5 bar
Mode: pressure
Temperature: −10…+60 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 38, 52, 65, 76, 102, 127, 152, 203, 254, 305, 356, 407
Working pressure, bar: 2, 3, 4, 5
Medium: Water
Mode: Pressure, layflat
Reinforcement: Circular woven textile
Temperature, °C: −10…+60
Tube material: PVC

Construction

Inner tube: Special high grade formulated PVC compound extruded through the weave in a unique one step production process. Very smooth for minimum friction loss
Reinforcement: Textile. High tenacity polyester yarn, special construction for low elongation. Totally embedded in the PVC compound, excellent protected against mechanical damage
Cover: Special high grade formulated PVC compound extruded through the weave in a unique one step production process. Much better adhesion level compared to conventional PVC layflat hoses, no delamination. Smooth for good flexibility. Light blue color

DELFLAT L sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Wall thickness, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Tensile strength, kg
38	645038041	1.3	5	15	0.205	100
52	645052055	1.3	5	15	0.38	100
65	645065068	1.5	4	12	0.38	100
76	645076079	1.7	4	12	0.53	100
102	645102106	1.8	4	12	0.71	100
127	645127131	1.9	3	9	0.95	100
152	645152156	2	3	9	1.18	100
203	645203207	2.2	3	9	1.79	100
254	645254259	2.7	2	6	2.65	100
305	645305310	2.7	2	6	2.91	100
356	645356361	2.7	2	6	3.65	100
407	645407412	2.7	2	6	4.3	100

Application and limits

Application: Lightweight PVC layflat hose for agriculture, industry and civil engineering.
Features: Very lightweight and highly flexible, small coil diameter, resistance to weathering and ozone, low elongation, excellent layer adhesion compared to conventional PVC layflat hose
Limits: Operating temperature from −10 to +60 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
Technical data based on water at a temperature of 20°C (68°F).
Depending on application and dimension of hose this product can be operated with a working pressure up to 50 % of the bursting pressure. Please consult us for approval.
Other lengths on request.
