DELFLAT HD hose with layers partly removed: inner tube, reinforcement and cover

DELFLAT HD Heavy duty polyurethane layflat hose

Heavy duty polyurethane layflat hose for demanding drainage and dewatering. Inner diameter 52–152 mm, working pressure up to 20 bar, temperature from −50 to +75 °C.

Inner diameter: 52–152 mm
Working pressure: up to 20 bar
Mode: pressure
Temperature: −50…+75 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 52, 65, 76, 90, 102, 114, 127, 152
Working pressure, bar: 10, 14, 16, 20
Medium: Abrasive media, manure and liquid fertiliser, slurry, waste water, water
Mode: Pressure, layflat
Reinforcement: Circular woven textile
Temperature, °C: −50…+75
Tube material: Polyurethane
Coil length, m: 100, 200

Construction

Inner tube: Thermoplastic polyether polyurethane extruded through the weave in a unique one step production process
Reinforcement: Textile. High tenacity polyester yarn, circular woven. Special weaving design for ultra-high tensile strength, minimum bending radius and low elongation under pressure. Totally embedded in the PU compound, excellent protected against mechanical damage
Cover: Thermoplastic polyether polyurethane extruded through the weave in a unique one step production process

DELFLAT HD sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Wall thickness, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Tensile strength, kg	Coil length, m
52	648052059	3.5	20	60	0.6	5000	100, 200
65	648065072	3.5	20	60	0.8	6500	100, 200
76	648076083	3.5	16	50	0.95	8000	100, 200
90	648090097	3.5	14	42	1.15	12000	100, 200
102	648102109	3.5	14	42	1.4	13500	100, 200
114	648114121	3.5	14	42	1.5	16000	100, 200
127	648127134	3.5	14	42	1.6	17500	100, 200
152	648152159	3.5	10	30	1.9	22500	100, 200

Application and limits

Application: Heavy duty polyurethane layflat hose for demanding drainage and dewatering.
Features: Superior abrasion resistance, extremely hardwearing and durable for long service life, ultra-high tensile strength, resistance to oil, fuel and a wide range of chemicals (see resistance table in technical appendix), resistance to weathering, UV and ozone, lightweight and easy to handle compared to material handling hose in rubber, excellent cold flexibility, single lengths longer than 200 m (660 ft), 52 - 90 mm (2 - 3 1/2″) up to 500 m (1,650 ft), 102 - 127 mm (4 - 5″) up to 400 m (1,320 ft)
Limits: Operating temperature from −50 to +75 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
Technical data based on water.
For air pressure the minimum safety ratio is 1:4.
Depending on the application our product can be operated with a maximum working pressure up to 50 % of the bursting pressure.
Please consult us for approval.
To obtain maximum lifetime the end pull under working conditions should not exceed 1/3 of the breaking strength.
Other lengths on request.
