DELFLEX AGRO 10 LF hose with layers partly removed: inner tube, reinforcement and cover

DELFLEX AGRO 10 LF Rubber layflat hose for water

Rubber layflat delivery hose for water, liquid fertiliser and non-corrosive inert fluids: submersible pumps, agricultural and industrial use. Inner diameter 40–609 mm, working pressure up to 10 bar, temperature from −30 to +80 °C.

Inner diameter: 40–609 mm
Working pressure: up to 10 bar
Mode: pressure
Temperature: −30…+80 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 40, 45, 51, 60, 70, 76, 80, 90, 102, 120, 152, 203, 254, 305, 350, 400, 457, 500, 609
Working pressure, bar: 5, 10
Medium: Manure and liquid fertiliser, water
Mode: Pressure, layflat
Reinforcement: Textile cord
Temperature, °C: −30…+80
Tube material: SBR
Coil length, m: 12, 20, 40, 61

Construction

Inner tube: SBR rubber, black, smooth
Reinforcement: High strength synthetic textile plies
Cover: SBR rubber, black, smooth, cloth impression, resistant to abrasion and weathering

DELFLEX AGRO 10 LF sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Weight, kg/m	Coil length, m
40	644040046	46	10	30	0.55	20, 40, 61
45	644045051	51	10	30	0.58	20, 40, 61
51	644051057	57	10	30	0.69	20, 40, 61
60	644060067	67	10	30	0.94	20, 40, 61
70	644070077	77	10	30	1.09	20, 40, 61
76	644076083	83	10	30	1.18	20, 40, 61
80	644080087	87	10	30	1.24	20, 40, 61
90	644090097	97	10	30	1.39	20, 40, 61
102	644102109	109	10	30	1.57	20, 40, 61
120	644120128	128	10	30	2.1	20, 40, 61
152	644152160	160	10	30	2.65	20, 40
203	644203215	215	10	30	5.32	20
254	644254267	267	10	30	7.18	20
305	644305319	319	10	30	9.26	20
350	644350365	365	5	15	10.7	20
400	644400417	417	5	15	13	12
457	644457476	476	5	15	18.4	12
500	644500524	524	5	15	23.75	12
609	644609635	635	5	15	31.2	12

Application and limits

Application: Rubber layflat delivery hose for water, liquid fertiliser and non-corrosive inert fluids: submersible pumps, agricultural and industrial use.
Features: Lays flat when empty
Limits: Operating temperature from −30 to +80 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
Layflat hoses are not suitable for suction.
