DELMARINE SAN 10 SD hose with layers partly removed: inner tube, reinforcement and cover

DELMARINE SAN 10 SD Odour-tight sanitation hose for boats

Suction and delivery hose for toilets and sanitary systems on board leisure boats up to 24 m; completely odour-tight. Inner diameter 19–45 mm, working pressure up to 10 bar, temperature from −40 to +120 °C.

Inner diameter: 19–45 mm
Working pressure: up to 10 bar
Mode: pressure and suction
Temperature: −40…+120 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 19, 25, 38, 40, 45
Working pressure, bar: 10
Medium: Waste water, water
Mode: Pressure and suction
Reinforcement: Textile cord, steel helix
Temperature, °C: −40…+120
Tube material: BIIR (butyl rubber)
Coil length, m: 40

Construction

Inner tube: Butyl rubber (BIIR), white, smooth, food quality, odourless and tasteless
Reinforcement: High strength synthetic textile plies, steel helix
Cover: EPDM rubber, white, smooth, cloth impression, resistant to abrasion, ozone and weathering

DELMARINE SAN 10 SD sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Vacuum, bar	Bend radius, mm	Weight, kg/m	Coil length, m
19	684019029	29	10	30	0.9	80	0.62	40
25	684025035	35	10	30	0.9	115	0.77	40
38	684038048	48	10	30	0.9	180	1.15	40
40	684040050	50	10	30	0.9	180	1.18	40
45	684045055	55	10	30	0.9	200	1.32	40

Application and limits

Application: Suction and delivery hose for toilets and sanitary systems on board leisure boats up to 24 m; completely odour-tight.
Features: Odour-tight butyl (BIIR) inner tube, white cover
Limits: Operating temperature from −40 to +120 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
For leisure boats up to 24 m long.
