DELMULTI 10 SD hose with layers partly removed: inner tube, reinforcement and cover

DELMULTI 10 SD Multipurpose suction and delivery hose, EPDM

Multipurpose EPDM suction and delivery hose for chemicals, hot water and sea water. Inner diameter 13–305 mm, working pressure up to 10 bar, temperature from −40 to +120 °C.

Inner diameter: 13–305 mm
Working pressure: up to 10 bar
Mode: pressure and suction
Temperature: −40…+120 °C

Request a quote

Delivery across Bulgaria by Econt and Speedy and across the EU — delivery terms.

We can assemble the hose with couplings and pressure test it — service.

Specifications

Inner diameter, mm: 13, 16, 19, 20, 25, 30, 32, 35, 38, 45, 51, 60, 63.5, 76, 90, 102, 110, 127, 152, 203, 254, 305
Working pressure, bar: 10
Medium: Chemicals, hot water, sea water
Mode: Pressure and suction
Reinforcement: Textile cord, steel helix
Temperature, °C: −40…+120
Tube material: EPDM
Coil length, m: 12, 20, 40, 61

Construction

Inner tube: EPDM rubber, black, smooth
Reinforcement: High strength synthetic textile plies, steel helix
Cover: EPDM rubber, black, smooth, cloth impression, resistant to weathering, sea water and heat

DELMULTI 10 SD sizes

Pressure in bar. The table scrolls sideways; the first column stays in place.

Inner diameter, mm	Article	Outer diameter, mm	Working pressure, bar	Burst pressure, bar	Vacuum, bar	Bend radius, mm	Weight, kg/m	Coil length, m
13	835013023	23	10	30	0.9	80	0.41	20, 40, 61
16	835016026	26	10	30	0.9	90	0.5	20, 40, 61
19	835019029	29	10	30	0.9	115	0.53	20, 40, 61
20	835020030	30	10	30	0.9	120	0.55	20, 40, 61
25	835025035	35	10	30	0.9	150	0.7	20, 40, 61
30	835030040	40	10	30	0.9	180	0.78	20, 40, 61
32	835032043	43	10	30	0.9	190	0.95	20, 40, 61
35	835035046	46	10	30	0.9	210	1.09	20, 40, 61
38	835038049	49	10	30	0.9	230	1.21	20, 40, 61
45	835045057	57	10	30	0.9	270	1.62	20, 40, 61
51	835051063	63	10	30	0.9	310	1.77	20, 40, 61
60	835060071	71	10	30	0.9	360	1.93	20, 40, 61
63.5	835063076	76	10	30	0.9	380	2.4	20, 40, 61
76	835076088	88	10	30	0.9	460	2.85	20, 40, 61
90	835090102	102	10	30	0.9	540	3.2	20, 40, 61
102	835102117	117	10	30	0.9	610	4	20, 40, 61
110	835110123	123	10	30	0.9	660	4.66	20, 40, 61
127	835127144	144	10	30	0.9	760	7	20, 40, 61
152	835152170	170	10	30	0.8	920	10	20, 40, 61
203	835203228	228	10	30	0.7	1220	17	20, 40
254	835254280	280	10	30	0.7	1524	20.35	20
305	835305331	331	10	30	0.5	2100	27	12

Application and limits

Application: Multipurpose EPDM suction and delivery hose for chemicals, hot water and sea water.
Features: Heat and sea water resistant cover, vacuum resistant, up to +120 °C
Limits: Operating temperature from −40 to +120 °C.
Working pressure depends on the inner diameter — see the table. Burst pressure is a reference value, not a working pressure.
